Castle Creations Mamba Micro X2 16.8V WP ESC 5600KV Sensored Motor (ONLINE ORDER ONLY)

Overview

The Castle Creations Mamba Micro X2 Combo (010-0171-05) delivers waterproof, sensored brushless power tuned for 1/18 scale RC. This factory-matched combo pairs the feature-rich Mamba Micro X2 ESC (16.8V / 4S capable) with a balanced 0808-5600kV brushless motor, providing strong acceleration and a slightly more controllable top end than the higher-KV variant.

The Mamba Micro X2 features Castle's CRYO-DRIVE thermal technology, full data logging, telemetry readiness, and an auxiliary wire for on-the-fly transmitter tuning. Sensored motor support delivers cog-free startup and exceptional low-speed control - critical for technical driving and lightweight crawler use.

The 0808-5600kV motor brings 4-pole brushless punch to 1/18 scale builds, making this combo a smart choice for 1/18 scale 2WD and 4WD vehicles up to 2.25 lbs that need strong, controllable power.

Key Features

• Factory-matched ESC and motor combo for 1/18 scale
• Waterproof Mamba Micro X2 ESC, 2S-4S capable
• 0808-5600kV brushless motor (4-pole)
• Sensored motor support for cog-free starts
• CRYO-DRIVE thermal management technology
• Data logging with downloadable analysis
• Auxiliary wire for on-the-fly transmitter tuning
• Telemetry-ready (S.BUS2 compatible)
• B-Link 2 Bluetooth programming compatible
• Audible alerts for diagnostics
• Genuine Castle Creations matched power system

Performance Benefits

• Strong acceleration with controllable top-end
• Cool, efficient operation thanks to CRYO-DRIVE
• Smooth, sensored low-speed control for technical driving
• On-the-fly tuning of max throttle, max brake, drag brake, and more
• Telemetry capability for advanced users
• Data logging supports informed setup decisions

Usage Notes

• Best used with 1/18 scale 2WD and 4WD RC vehicles up to 2.25 lbs
• Compatible vehicles include: Traxxas Slash 4x4 1/16, Losi Mini-T 2.0, Traxxas LaTrax Rally, Traxxas LaTrax Teton, Axial Yeti Jr.
• Also works in some 1/10 scale crawlers for low-speed operation (no rock racing or hill climbing)
• Use 2S-4S LiPo (4-9 cell NiMH)
• Rinse with fresh water after wet running and dry fully

Technical Specs

ESC Specifications - Mamba Micro X2

• Brand: Castle Creations
• Model: Mamba Micro X2
• ESC Type: Brushless (sensored capable)
• Input Voltage Range: 2S - 4S LiPo (up to 16.8V)
• Waterproof: Yes
• Internal BEC: Yes (units made June 2023 or later)
• Data Logging: Yes
• Telemetry Capable: Yes (S.BUS2)
• Auxiliary Wire: Yes
• B-Link Compatible: Yes
• CRYO-DRIVE: Yes

Motor Specifications - 0808-5600kV

• Brand: Castle Creations
• Motor Size: 0808 (20mm)
• KV Rating: 5600kV
• Motor Type: Brushless
• Pole Count: 4-Pole
• Connectors: 3.5mm Male Bullets (pre-installed)
• Mounting Holes: 2.5mm @ 14mm

Combo Information

• Scale Compatibility: 1/18 scale 2WD/4WD up to 2.25 lbs
• Application: Micro racing, bashing, light crawling
• Warranty: 1 year (Olathe, KS USA)
• Part Number: 010-0171-05

What's Included

• 1 x Castle Creations Mamba Micro X2 waterproof sensored ESC
• 1 x Castle Creations 0808-5600kV brushless motor
• Quick Start Guide
• Castle Decals

Fitment

Compatible Vehicles: Traxxas Slash 4x4 1/16, Losi Mini-T 2.0, Traxxas LaTrax Rally, Traxxas LaTrax Teton, Axial Yeti Jr.

Summary

The Mamba Micro X2 + 0808-5600kV combo strikes the perfect balance of speed and control for 1/18 scale RC. Sensored, waterproof, data-logged, and Castle-built, it's the ideal upgrade for serious micro-scale drivers.
